Wulian Smart Human Presence Sensor
Product Code: MSA045 Z
Brand: Wulian
Detect multiple types of human activity status with a built-in microwave sensor.
Strong anti-interference ability to resist winged insects, ventilation and wireless signals.
With a light sensing ability to fit for more scenarios.
App remote check and alarm notification, also can link with other smart home devices.
Living body detection is used as a security feature to prevent unauthorized access.
Smart system linkage control allows it to work with smart home systems as a switch to control lighting, making it energy-efficient and environmentally friendly.
The built-in light sensor (LUX detector) enables automatic curtain control based on light intensity. Message push support allows wireless APP control and customized linkage settings, with real-time status reporting to the cloud for instant alerts and smart home automation.
1 year warranty.
Function:
Living body presence detection technology. With a built-in microwave sensor of living body and light sensor, it's able to detect precisely and distinguish between motion, small motion and breath, and then link to control different lights, AC , background music, etc.
Application:
1. It can be used in home, office, classroom, meeting room, hotel, bathroom and library.
2. Detection of multiple status. Different response to general motion, small motion and stillness.
• Normal activity status, light is bright.
• Leisure status, light is soft.
• Rest and sleep, light turns off gently.
Technology:
1. Living body detection technology
Based on 5.8GHz microwave breath detection technology, by adopting low-independence antenna and special presence. Algorithm and detecting chest expansion during breath to detect living body presence. Meanwhile, with algorithm and microwave, it's available to avoid AC, ventilation airflow interference, so as to detect living body breath accurately.
2. Strong anti-interference ability with low-impedance antenna.
Patented low-impedance antenna fits for last RED command requirement and is able to effectively resist winged insect, ventilation and wireless signal of WI-Fl, Bluetooth. 4G/5G
3. Independent embedded installation design. Embedded installation design is consistent with LED light's installation condition, making presence sensor adapt to existed lighting environment and avoiding any destroy to current decoration
Specifications:
| Power Supply | 120-277Vac, 50/60Hz |
| Standby Power | ≤1.5W |
| Sensitivity Settings | 0% / 25% / 50% / 75% / 100% |
| Delay Settings | 30s, 1 min, 2 min, 3 min, 5 min, 10 min, 20 min |
| Detection Distance | 3-5m radius for motion, 3-4m for small motion (moving head or arms), 2-3m for breath detection (being still) |
| Installation Method | Ceiling mounted (2.5-4m height) |
| Features | Detects multiple types of human activity using a built-in microwave sensor |
| Strong resistance to interference from insects, ventilation, and wireless signals | |
| Light-sensing capabilities for enhanced scenario adaptability | |
| Remote app monitoring and alarm notifications | |
| Application | Smart home security, motion detection automation |
