FritsJurgens - Adjustable Pivot Hinge System One
Product Code: HDH/PVST.ONE.70.G.SN.SS
Brand: FritsJurgens
The Pivot Door Hinge System One Of FritsJurgens Is Completely Mortised In The Door:
- Compact System
- No Hold Positions Or Closure Function
- Can Be Combined With Door Frames
Components
A pivot door needs various components:
- The pivot system
- A floor plate
- A ceiling plate
- A top pivot
| Movement | The System One Pivot Door Hinge Can Be Opened To Both The Left And The Right, Turns Through 360˚ And Has No Hold Positions Or Closure Function. It Is Possible To Combine System One With Door Frames; In This Case The Door Rotation Is 90˚. |
| Maximum Bearing Capacity | 500kg |
| Minimum Door Thickness | 40 mm |
| Hold Positions | None |
| Minimum Dimensions Around The Door For Fitting | Below: 13 mm Above: Minimum 4 mm, Maximum 10 mm. Door/Closing Side:: Cap Calculation
|
| Minimum Distance From The Pivot Point To The Side Of The Door | 91mm |
| Maximum Door Dimensions | Unrestricted Up To A Maximum Weight Of 500 Kg (System Selector). |
| Special Doors | FritsJurgens System One Is Suitable For Fire-Resistant Doors, Soundproof Doors, Doors With Draught-Excluding, Windproof And Waterproof Profiles, And Burglar-Resistant Doors. For More Information Please Contact One Of Our Dealers Or Partners In Your Area. |
| Floating Floors / Suspended Ceilings | It Is Possible To Fit A Pivot Door If The Floor Plate Or Ceiling Plate Is Connected To The Structural Subfloor Or Ceiling. |
| Packaging | Delivered As A Complete Set With Top Pivot, Floor Plate, Ceiling Plate And Fitting Accessories. |
Technical Specifications
| System specifications | |
| Types | 2 |
| Dimensions | 162 x 32 x 18 mm |
| Weight | 0,36 KG |
| Door specifications | |
| Door Acting | Double-acting | 360° rotation Single-acting | 90° rotation |
| Hold positioning | __ |
| Weight capacity | 0 - 500 kg |
| Door width | Unlimited |
| Door height | Unlimited |
| Pivot point | Side and middle |
| Min. door thickness | 40 mm |
| Top gap | 4-10 mm |
| Bottom gap | 7 mm - 11 mm |
| Door movement | 360° free-swinging pivot |
