FritsJurgens - Adjustable Pivot Hinge System 3

Movement

Thanks To The Innovative Design Of System 3, The Door Requires A Slight Touch To Start Moving, Then It Continues To Rotate By Itself Thanks To The Patented Spring Construction. The Spring-Loaded Door Turns From Each 45º In Both Directions And Stops In The Desired Direction. Thanks To Precise Damping The Door Comes To Rest In The Hold Position After Two Movements.

Maximum Load-Bearing Capacity

500 Kg

Minimum Door Thickness

40 Mm

Minimum Dimensions Around The Door For Fitting

Below: 13 Mm

Above: Minimum 4 Mm, Maximum 10 Mm

Door/Closing Side: Cap Calculation

Hold Positions

0º, 90º, 180º En 270º

Minimum Distance From The Pivot Point To The Side Of The Door

91 Mm.

Maximum Door Dimensions

Unrestricted Up To A Maximum Weight Of 500 Kg (Type Selector)

Special Doors

FritsJurgens System3 Is Suitable For Soundproof Doors, Doors With Draught-Excluding, Windproof And Waterproof Profiles, And Burglar-Resistant Doors. For More Information Please Contact One Of Our Dealers Or Partners In Your Area.

Floating Floors / Suspended Ceilings

It Is Possible To Fit A Pivot Door If The Floor Plate Or Ceiling Plate Is Connected To The Structural Subfloor Or Ceiling.

Packaging

Delivered As A Complete Set With Top Pivot, Floor Plate, Ceiling Plate And Fitting Accessories.

Components

Ceiling Plates

The ceiling plate is fitted in the ceiling, where the pin of the top pivot seamlessly fits into the hole in the ceiling plate. The ceiling plate is available in two finishes: brushed stainless steel and black.

Top Pivot

The top pivot is mounted into the top of the door. It uses a so-called pinhole connection, in which the pin is fixed to the top pivot and goes into the hole in the ceiling plate when the door is placed.

Floor Plates

Every FritsJurgens floor plate is mounted 8 mm in the floor. This is sufficient for almost every floor type and makes it possible to combine FritsJurgens’ hinges with floor heating.

Bottom Pivot

The bottom pivot is the pivot mechanism and driver of the pivot door and is fitted in the bottom side of the door. The pivot mechanism therefore is virtually invisible. FritsJurgens bottom pivots have a load bearing capacity for pivot doors up to 500 Kg.

 The bottom pivot offers several features, depending on the choice of bottom pivot, such as: hold positions, self-closing, and damper control, latch control, 30° speed control, free swing.

The bottom pivots placement determines the the spatial impact that the pivot door will have on its surroundings. Besides a more regular side placement to create pivot doors, FritsJurgens pivot hinges are also suitable for 360 degree rotating panels or walls.
