DSPPA 6.5 Inch Surface Mount Ceiling Speaker
Product Code: DSP5311
Brand: DSPPA
The DSP5311 is a surface mount ceiling speaker with a 70v/100v transformer built in. The 70v/100v transmission is realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel connection of multiple loudspeakers possible. The speaker is made of high-quality engineering plastic, has long-term durability, never out of shape and fading; No roof cutout direct mounting on the ceiling by 4 screws ; 6.5-inch driver unit, with a large and special magnetic circuit ensures strong power. It is an ideal choice for these places, such as schools, gymnasiums, square halls, parks, parking lots, railway stations, airports, villa communities and mall supermarkets, etc.
Features:
- 6.5-inch driver unit, large and special magnetic circuit ensures strong power.
- Full range driver unit design, perfectly realize the reproduction of voice and music.
- The appearance is designed in a circular shape, showing the conciseness and elegance and leading the fashion trend. Carbon alloy aluminum grille, with RAL white layer, can perfectly comply with any indoor venue.
- Comply with IEC 268-5 (PHC) standards, can work with RMS power for 100 hours continuously, can support instant output of twice RMS power.
- The ceiling is designed on an open-installation basis, so as to relieve the procedure for cutting the hole.
Specification:
| Model | DSP5012 |
| Unit Driver | 8"×1 |
| Rated Power | 35W |
| Impedance | 70V/100V |
| Sensitivity (1m, 1W) | 88±3dB |
| MAX. SPL. (1m) | 103±3dB |
| Freq. Resp. | 55Hz-20KHz |
| Dimension | Φ262×100mm |
| Weight | 2kg |
