DSPPA 6 Zones Digital Mixer Amplifier
Brand: DSPPA
Speaker output: 70V/100V & 4-16Ω
Rated power: 250W
Input source: 4 Mic, 4 AUX and USB/FM/Bluetooth/TF
Support 2 remote paging microphones.
With 19" rack mount handles.
Phoenix port for Mic2-4 input ,Line2 input ,EMC input.
Mute and Siren.
Mic 2-4 with phantom power 48V.
Individual volume control and Bass/Treble adjustment.
Priority: MUTE>EMC IN=SIREN>MIC1=CHIME=
Remote Mic>Mic2-Mic4/AUX input/Bluetooth/FM/USB
Protection: Overload, Clipping, Short circuit and temperature protection
Power supply: AC220V-230V/50Hz/60Hz or DC24V
Specification
Input Sensitivity
MIC1: 5mV ±1mv (Balanced XLR Input)
MIC2/MIC3/MIC4: 5mV ±1mv (Unbalanced Phoenix Jacks)
AUX: 350mV±50mv (Unbalanced RCA Input)
AUX2: 350mV ±50mv (Unbalanced Phoenix Jacks)
EMC: 350mV ±50mv (Unbalanced Phoenix Jacks)
MIC Frequency Response: 120Hz～12kHz (±3dB)
AUX Frequency Response: 80Hz～15kHz (±3dB)
THD: <1%
Treble Adjustment Range: 10dB（±2）
BASS Adjustment Range : 10dB（±2）
Phantom Power: +48V
Output Voltage of Port: 4-16Ω,70V,100V (fixed voltage output)
Machine Dimension(D×W×H): 430×390×88mm
Package Dimension: 545×500×165mm
