Wulian Salute Switch Serial
- View all variations as list
| CODE | Color | No. of Gangs | Required Wire | Availability | Price | ||
|---|---|---|---|---|---|---|---|
|
ZY-ZCSFLPW-D11011-0 G1GL+N
|
In stock
|
AED14500 | ||||
|
|
ZY-ZCSFLPW-D1111-0 G2GL+N
|
In stock
|
AED15500 | ||||
|
|
ZY-ZCSFLPW-D1111-0 G3GL+N
|
In stock
|
AED17024 | ||||
|
ZY-ZCSFLPW-D1111-0 W1GL&L+N
|
In stock
|
AED17024 | ||||
|
ZY-ZCSFLPW-D1111-0 W2GL&N
|
In stock
|
AED15500 | ||||
|
|
ZY-ZCSFLPW-D1111-0 W2GL&L+N
|
In stock
|
AED20500 | ||||
|
ZY-ZCSFLPW-D1111-0 W3GL&N
|
In stock
|
AED17024 | ||||
|
|
ZY-ZCSFLPW-D1111-0 W3GL&L+N
|
In stock
|
AED21014 | ||||
|
|
ZY-ZCSFLPW-D1111-0 W1GL&N
|
In stock
|
AED14500 |
Brand: Wulian
Salute series switch integrates conventional switch design with modern smart functions, providing you distinctive living experience.
Sleek surface design.
Integrated Switch, Socket, Scene Switch and Thermostat.
Unified style, allowed to combine freely.
APP control and local control.
Multiple modes available, such as scenario, on/off and binding.
1 Year Warranty.
Parameters
Power: 100~240V AC, 50/60Hz
Communication mode: IEEE802.15.4 (Zigbee)
Maximum load power: 300W
Working conditions: -10~45℃ , ≤ 95%（No condensation）
Storage conditions: -20~70℃ , ≤ 95>%（No condensation）
General Specification
Installation site: Interior
Material: Polycarbonate
Material option: ABS
Product type: Switch
Size
Height: 86 mm
Weight: 195 gr
Width: 86 mm
Technical
Communication Protocol: IEEE 802.15.4(ZigBee/Smart Room)
Features: Supports timing /detecting signal intensity/setting linkage and scenarios. Can link with other smart devices to realize device linkage. Supports binding and scene function.
Fire Rating: UL94-V0
Installation Method: Wall-mounted Type
Max. Output Power (Each Gang) : 500W (Resistive) / 300W (Inductive or Capacitive)
Standby Power Consumption: ≤0.5W
