Blum - CLIP Top 107° Standard Hinge + Aluminium Mounting Plate

74T1790BTL/175L6600.22
AED923
Excl. VAT
1 Set (AED9.23 per Set)
In stock
Price in points: 10 points

Brand: Blum

For front thicknesses starting from 15mm. CLIP top with or without closing mechanism (spring). 107° opening angle. 3-dimensional front adjustment. Convenient spiral-tech depth adjustment. Tool-free door to cabinet assembly and removal. With INSERTA tool-free hinge to door assembly.


Technical Attributes

Application: Standard Hinge

Opening Angle:107

Boss Material: Steel Boss

Boss Finish: Nickel Plated

Diametre Hinge Boss Drilling: 35

Distance Between Drillings: 45

Eccentric Position of Fixing Holes to Hinge Boss Hole: 9.5

Boss Drilling Depth:11.5

Minimum Drilling Distance:3

Maximum Drilling Distance: 6

Arm Material: Steel

Arm Finish: Nickel Plated

Type of Side Adjustment: With Screw

Side Adjustment: +/- 2 mm

Type of Depth Adjustment: Convenient with Spiral Screw

Depth Adjustment: + 3/- 2 mm

Gap: 1.5

Item Package: 1 Piece


Blum CLIP Top - Aluminium Mounting Plate (Screw On) - Nickel Plated Finish

Technical Attributes

Mounting Plate System: CLIP

Colour / Finish: Nickel Plated

Shape of Mounting Plate: Cruciform

Material: Zinc

Mounting Plate Variant: Special Dimension A 12.5 mm

Mounting Plate Variant: Face Frame Construction/Stop Flanges

Mounting Plate Variant: Additional Fixing Hole

Fixing: For Chipboard Screws

Distance Cabinet Front Edge to First Fixing Position: 12.5

Mounting Plates Height Adjustment: With Elongated Hole

Height Adjustment: +/- 3 mm

Height: 8.5

Spacing: 0

Angle: 0

Item Package: 1 Piece


Brand
Blum
Cup Fixing Type
Inserta
